Downlight LED Range
MyLite LED downlight series provides turn-key lighting solutions for domestic and commercial applications. We offer our customers a platform to experience superb quality and dazzling lighting effects with unique design, 100lm/w, UGR19, Ra80 and Ra90, smart function design.
Featured LED Ranges:
Mini LED
Cutout Size: Ø68-74mmBeam Angle: 24°/36°/60°
Protection Grade: IP54
SMD LED
Cutout Size: Ø90-95mmBeam Angle: 90°
Protection Grade: IP54
Adjustable COB LED
Product Size: Ø90*46mmBeam Angle: 24°/60°
Protection Grade: IP20
Rectangular LED
Beam Angle: 120°Rotation Angle: 90° vertical
Protection Grade: IP20/IP65
Adjustable LED
Beam Angle: 90°Size: Ø110*41.5mm
Protection Grade: IP20
Wifi controlled LED
Intelligent lighting control system: Dimmable, colour changeable, timing and memory.Specifications:
| Name | Image | Code # | Description | Dimension | cutout size | voltage | CCT | LED | POWER | BEAM
ANGLE |
LUMENS |
|---|---|---|---|---|---|---|---|---|---|---|---|
| LED Downlight |
|
ML-DL4870 8W |
Ø85*45mm |
70-75mm |
AC185-265V |
Warm White |
Epistar |
8W |
120° |
640 lm |
|
| LED Downlight |
|
ML-UPCL
|
Ø90*46mm |
84mm |
AC200-265V |
Warm White |
Epistar |
10W |
60° |
850- |
|
| LED Downlight |
|
ML-DL4890 10W |
Ø110*45mm |
90-95mm |
AC185-265V |
Warm White |
Epistar |
10W |
120° |
850 lm |
|
| LED Downlight |
|
ML-DL4890 13W |
Ø110*45mm |
90-95mm |
AC185-265V |
Warm White |
Epistar |
13W |
120° |
1100 lm |
|
| LED Downlight |
|
ML-UPCL59-
|
Ø120*39mm |
AC200-265V |
Warm White |
Epistar |
13W |
90° |
990-1100 lm |
||
| LED Downlight |
|
ML-UPCL59-3.5-13W-
|
With Wifi |
Ø110*38mm |
90-100mm |
AC100-265V |
Changeable by remote |
Epistar |
13W |
90° |
850-900 lm |
| LED Downlight |
|
Remote Controller 4.2101.00.02800 |
2.4 RF Remote controller, control distance 20-30m for ML-UPCL59-3.5- |
||||||||
| LED Downlight |
|
ML-UPCL59-3-13W-
|
3 inch multiswitch downlight |
Ø110*38mm |
90-100mm |
AC200-265V |
Warm White |
Epistar |
13W |
90° |
850-900 lm |
| LED Downlight |
|
ML-UPCL30-
|
Ø110*41.5mm |
95-100mm |
AC200-265V |
Warm White |
Epistar |
13W |
90° |
760-900 lm |
|
| LED Downlight |
|
ML-DL48120 15W |
Ø140*45mm |
120-130mm |
AC185-265V |
Warm White |
Epistar |
15W |
120° |
1200 lm |
|
| LED Downlight |
|
ML-DL48140 15W |
Ø160*45mm |
120-145mm |
AC185-265V |
Warm White |
Epistar |
15W |
120° |
1200 lm |
|
| LED Downlight |
|
ML-DL48150 20W |
Ø168*45mm |
150-160mm |
AC185-265V |
Warm White |
Epistar |
20W |
120° |
1600 lm |
|
| LED Downlight |
|
ML-DL48170 25W |
Ø180*45mm |
150-170mm |
AC185-265V |
Warm White |
Epistar |
25W |
120° |
2000 lm |
|
| LED Downlight |
|
ML-DL48200 20W |
Ø230*50mm |
190-210mm |
AC185-265V |
Warm White |
Epistar |
20W |
120° |
2400 lm |
|
| LED Downlight |
|
ML-DL48200 24W |
Ø230*50mm |
190-210mm |
AC185-265V |
Warm White |
Epistar |
24W |
120° |
2800 lm |
|
| LED Downlight |
|
ML-DL48200 30W |
Ø230*50mm |
190-210mm |
AC185-265V |
Warm White |
Epistar |
30W |
120° |
2400 lm |
|
| LED Downlight |
|
ML-DL48200 35W |
Ø230*50mm |
190-210mm |
AC185-265V |
Warm White |
Epistar |
35W |
120° |
2800 lm |
|
| LED Downlight |
|
ML-DL4890S 10W |
110*110*42mm |
92-100mm |
AC185-265V |
Warm White |
Epistar |
10W |
120° |
800 lm |
|
| LED Downlight |
|
ML-DL4890S 13W |
110*110*42mm |
92-100mm |
AC185-265V |
Warm White |
Epistar |
13W |
120° |
1100 lm |
|
| LED Downlight |
|
ML-DL55 9W |
Ø90*49mm |
65-80mm |
AC185-265V |
Warm White |
Epistar |
9W |
120° |
700 lm |
|
| LED Downlight |
|
ML-DL4970 8W |
Ø90*31mm |
70-80mm |
AC185-265V |
Warm White |
Epistar |
8W |
120° |
640 lm |
|
| LED Downlight |
|
ML-DL4910W |
Ø100*31mm |
85-90mm |
AC185-265V |
Warm White |
Epistar |
10W |
120° |
800 lm |
|
| LED Downlight |
|
ML-DL49 13W |
Ø100*31mm |
85-90mm |
AC185-265V |
Warm White |
Epistar |
13W |
120° |
1100 lm |
|
| LED Downlight |
|
ML-DL56 20W |
Ø170*32mm |
150-160mm |
AC185-265V |
Warm White |
Epistar |
20W |
120° |
1600 lm |
|
| LED Downlight |
|
ML-DL57 20W |
Ø230*60mm |
190-210mm |
AC185-265V |
Warm White |
Epistar |
20W |
120° |
2400 lm |
|
| LED Downlight |
|
ML-DL57 24W |
Ø230*60mm |
190-210mm |
AC185-265V |
Warm White |
Epistar |
24W |
120° |
2800 lm |
|
| LED Downlight |
|
ML-DL57 30W |
Ø230*60mm |
190-210mm |
AC185-265V |
Warm White |
Epistar |
30W |
120° |
2400 lm |
|
| LED Downlight |
|
ML-DL57 35W |
Ø230*60mm |
190-210mm |
AC185-265V |
Warm White |
Epistar |
35W |
120° |
2800 lm |
|
| LED Downlight |
|
ML-DL5990 10W |
Ø110*63mm |
88-100mm |
AC185-265V |
Warm White |
Epistar |
10W |
120° |
850 lm |
|
| LED Downlight Square |
|
ML-DL28 10W |
140x140x57mm |
125X125mm |
AC185-265V |
Warm White |
Epistar |
10W |
120° |
850 lm |
|
| LED Downlight Square |
|
ML-DL29 20W |
180x180x67mm |
160X160mm |
AC185-265V |
Warm White |
Epistar |
20W |
120° |
1700 lm |
|
| LED Downlight Square |
|
ML-DL30 30W |
220x220x67mm |
195X195mm |
AC185-265V |
Warm White |
Epistar |
30W |
120° |
2500 lm |
|
| LED Downlight Square |
|
ML-DL27 28W |
230*145*137mm |
210x125mm-230x140mm |
AC185-265V |
Warm White |
Epistar |
28W |
120° |
2700 lm |
|
| LED Downlight Square |
|
ML-DL27 38W |
230*145*137mm |
210x125mm-230x140mm |
AC185-265V |
Warm White |
Epistar |
38W |
120° |
3700 lm |
|
| LED Downlight Square |
|
ML-DL27 45W non-dimmable |
230*145*137mm |
210x125mm-230x140mm |
AC185-265V |
Warm White |
Epistar |
45W |
120° |
4500 lm |
|
| LED Downlight Square |
|
ML-DL27 50W non-dimmable |
230*145*137mm |
210x125mm-230x140mm |
AC185-265V |
Warm White |
Epistar |
50W |
120° |
5000 lm |
|
| LED Downlight Square |
|
ML-DL27 60W non-dimmable |
230*145*137mm |
210x125mm-230x140mm |
AC185-265V |
Warm White |
Epistar |
60W |
120° |
6000 lm |
